AUTOMOTIVE
New Bi-level, Tri-level or adjustable deck auto racks meeting National Reload Pool service requirements for the transportation of new motor vehicles from North American manufacturers or import terminals to retail dealers.
70/89
|
|
---|---|
Overall Length, inside | 89′ 9″ |
Overall Length Over Couplers | 93′ 10″ |
Estimated Useful Load | 80,000 lbs. |
Gross Rail Load | 195,000 lbs |
Light Weight | 115,000lbs |
Width (extreme) | 10′ 8″ |
Height (extreme) | 19′ |
AAR Clearance Profile | Plate “J” |
**General car dimensions and car specifications are illustrative, for general information purposes only and many not be representative of actual car. Actual car design capacities and weights are subject to confirmation and may change without notice.
