FRAC SAND
Covered hoppers specifically designed for frac sand and other high-density, dry bulk products are available from 3,250 to 3,280 cubic feet.
3250
|
|
---|---|
Cubic Capacity | 3250 cu. ft. |
Gross Rail Load Pounds | 286,000 lbs. |
Typical Light Weight Pounds | 55,000 lbs. |
Estimated Useful Load | 231,000 lbs. |
AAR Clearance Profile | Plate “C” |
Loading Hatches Diameter | 20″ or 30″ |
Loading Hatches per Car | 3 or 4 |
Gravity Discharge Gate Outlets per Car | 2 |
Gravity Discharge Gate Outlets per Car | 3 |
Discharge Gate Dimensions | 13″ x 42″ |
Extreme Height | 15′ 6″ |
Extreme Width | 10′ 8″ |
Length Over Couplers | 42′ |
Vibrator Brackets | 4 |
**General car dimensions and car specifications are illustrative, for general information purposes only and many not be representative of actual car. Actual car design capacities and weights are subject to confirmation and may change without notice.
